Place of Origin : China
Model Number : OC0004
MOQ : 1
Price : $100.55-125
Pixel Pitch : 2.604mm, 2.97mm, 3.91mm, 4.81mm
Pixel Matrix : 147475, 112910, 65410, 43222 per Sq.m
Pixel Configuration : SMD1515, SMD2121, SMD2525
Scan : 1/32, 1/28, 1/16, 1/13
Brightness : ≥600-800 cd/㎡ (indoor), ≥4500 cd/㎡ (outdoor)
Module Size : 250×250mm
Cabinet Size : 500x500mm (V), 500x1000mm (H)
Cabinet Material : Die Casting Aluminum
Cabinet Weight : 8KG (V), 15KG (H)
Power Consumption : 800W/200-300W per Sq.m
Service Access : Front/Rear
Refresh Rate : ≥3840Hz
Grey Scale : ≥16 bit
Viewing Angle : 160° (H/V)
IP Rate : IP43 (indoor), IP65 (outdoor)
Input Voltage : 110V / 240V AC




Model | P2.604 | P2.97 | P3.91 | P4.81 | |||||
Pixel Pitch(mm) | 2.604 | 2.97 | 3.91 | 4.81 | |||||
Pixel Matrix Per Sq.m | 147475 | 112910 | 65410 | 43222 | |||||
Pixel Configuration | SMD1515 | SMD1515 | SMD2121 | SMD2525 | |||||
Scan | 1/32 | 1/28 | 1/16 | 1/13 | |||||
Brightness (cd/㎡) | indoor screen ≥600-800, outdoor screen ≥4500 | ||||||||
Module Size | 250×250mm | ||||||||
Cabinet Size | V -- 500x500mm/H -- 500x1000mm | ||||||||
Cabinet Material | Die Casting Aluminum | ||||||||
Cabinet Weight | V -- 8KG/H -- 15KG | ||||||||
Power Con.(W/㎡) (Max / Avg) | 800W/200-300W | ||||||||
Service Access | Front/Rear | ||||||||
Refresh Rate (HZ) | ≥3840Hz | ||||||||
Grey Scale (bit) | ≥16 | ||||||||
Viewing Angle (H/V) | 160°/160° | ||||||||
IP Rate | indoor screen is IP43, outdoor screen is IP65 | ||||||||
Input Voltage (AC) | 110V / 240V | ||||||||









|
|
P3.91 Rental LED Display with 5 Years Warranty and 5500 cd Brightness for Indoor and Outdoor Video Wall Images |
